AC1200 Wi-Fi Mesh 4G LTE Router ( LT500 )

Model Version LT500 2.0 CPU Chipset MT7628A+MT7613B CPU Details 580 MHZ Single-Core, MIPS24KEC Memory/Stroage Flash/ROM 16 MB (128 Mbit) NOR DDR/RAM 128 MB (1 Gbit) DDR3 Cellular Celluar Standards 4G Cat. 4 Cellular Antennas 2× Fixed SIM Options 1× Nano SIM Slot Available Versions Version EU, US, AU EU Suitable Region Europe, Middle East, Africa EU Max DL Speed 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) EU Max UL Speed 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) EU Cellular Features DL 2×2 MIMO EU Celluar Bands LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: B38/40/41 WCDMA: B1/5/8 US Suitable Region United States, Canada US Max DL Speed 150 Mbps US Max UL Speed 50 Mbps US Cellular Features DL 2×2 MIMO US Celluar Bands LTE-FDD: B2/4/5/12/13/14/66/71 WCDMA: B2/4/5 AU Suitable Region Latin America, Australia, New Zealand AU Max DL Speed 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) AU Max UL Speed 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) AU Cellular Features DL 2×2 MIMO AU Celluar Bands LTE-FDD: B1/2/3/4/5/7/8/28/66 LTE-TDD: B40 WCDMA: B1/2/4/5/8 GSM: B2/3/5/8 Wireless 5 GHz Wi-Fi Speed 867 Mbps Wi-Fi Bands EU 2.4 GHz Wi-Fi Speed 300 Mbps 5 GHz Wi-Fi Streams 2T2R (2×2 MIMO) 2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO) Wi-Fi Antennas 2× Fixed 5 GHz Anntenna Gain Max 4.8dBi 2.4 GHz Antenna Gain Max 5.19dBi FEM or PA/LNA 5 GHz: 2× Internal 2.4 GHz: 2× Internal Wi-Fi Transmission Power CE: <20 dBm (2.4 GHz) <23 dBm (5.15 GHz ~ 5.35 GHz) FCC: <24 dBm (5.25 GHz ~ 5.35 GHz & 5.47 GHz ~ 5.725 GHz) <30 dBm (2.4 GHz & 5.15 GHz ~ 5.25 GHz) Range Performance Max: 100 m (328 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. Wall Performance Two wooden walls with thickness < 3.8 cm (1.5”) One concrete wall with thickness < 10 cm (4”) Interfaces Physical Buttons WPS Button Reset Button 10/100 Mbps RJ45 Ports 4 Ethernet Notes One port supports WAN/LAN configuration, and the rest are LAN ports LED System Speed/Link/ACT of Each Ethernet Port Power Input DC Jack Power Power Methods DC DC 12V 1A Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC Reliability ESD Air Protection 4kV ESD Contact Protection 8kV Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing Package Content Main Product Power Adapter Ethernet Cable Installation Guide Mechanical Dimension 204.8×133.2×38.3 mm 8.06×5.24×1.51 inches Installation Desktop Wall-Mounting
