wAP LTE kit

Specifications Details Product code RBwAPR-2nD&R11e-LTE Architecture MIPSBE CPU QCA9531 CPU core count 1 CPU nominal frequency 650 MHz Dimensions 185 x 85 x 30 mm License level 4 Operating System RouterOS Size of RAM 64 MB Storage size 16 MB Storage type FLASH Tested ambient temperature -40°C .. 60°C tested Powering Details Max Power consumption 8W PoE in Passive PoE PoE in input Voltage 9-30 V Number of DC inputs 3 (Automotive, DC jack, PoE-IN) DC jack input Voltage 9-30 V Automotive input Voltage 9-30 V Mobile Details 2G Category Class12 3G Category R7 (21Mbps Downlinks, 5.76Mbps Uplink) LTE Category 4 (150Mbps Downlink, 50Mbps Uplink) LTE FDD bands 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) LTE TDD bands 38 (2600MHz) / 40 (2300MHz) Wireless Details Wireless 2.4 GHz number of chains 2 Wireless 2.4 GHz standards 802.11b/g/n Antenna gain dBi for 2.4 GHz 2 Wireless 2.4 GHz chip model QCA9531 Ethernet Details 10/100 Ethernet ports 1 Peripherals Details Number of SIM slots 1 Modem (Mini SIM) MiniPCI-e slots 1 Other Details PCB temperature monitor Yes Voltage Monitor Yes Wireless specifications 2.4 GHz Transmit (dBm) Receive Sensitivity 1MBit/s 22 -96 11MBit/s 22 -89 6MBit/s 20 -93 54MBit/s 18 -74 MCS0 20 -93 MCS7 16 -71
