N300 Wi-Fi 4G LTE Router ( LT400_EU )

Model Version LT400 2.0 CPU Chipset MT7628DA CPU Details 580 MHZ Single-Core, MIPS24KEC Memory/Stroage Flash/ROM 8 MB (64 Mbit ) NOR DDR/RAM 64 MB (512 Mbit) DDR3 Cellular Celluar Standards 4G Cat. 4 Cellular Antennas 2× Fixed SIM Options 1× Nano SIM Slot Available Versions Version EU, US, AU EU Suitable Region Europe, Middle East, Africa EU Max DL Speed 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) EU Max UL Speed 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) EU Cellular Features DL 2×2 MIMO EU Celluar Bands LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: B38/40/41 WCDMA: B1/5/8 US Suitable Region United States, Canada US Max DL Speed 150 Mbps US Max UL Speed 50 Mbps US Cellular Features DL 2×2 MIMO US Celluar Bands LTE-FDD: B2/4/5/12/13/14/66/71 WCDMA: B2/4/5 AU Suitable Region Latin America, Australia, New Zealand AU Max DL Speed 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) AU Max UL Speed 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) AU Cellular Features DL 2×2 MIMO AU Celluar Bands LTE-FDD: B1/2/3/4/5/7/8/28/66 LTE-TDD: B40 WCDMA: B1/2/4/5/8 GSM: B2/3/5/8 CN Suitable Region China, India CN Max DL Speed 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) CN Max UL Speed 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) CN Cellular Features DL 2×2 MIMO CN Celluar Bands LTE-FDD: B1/3/5/8 LTE-TDD: B34/38/39/40/41 WCDMA: B1/5/8 GSM: B3/8 Wireless 2.4 GHz Wi-Fi Speed 300 Mbps 2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO) Wi-Fi Antennas 2× Fixed Wi-Fi Transmission Power CE: <20 dBm (2.4 GHz) FCC: <30 dBm (2.4 GHz) Range Performance Max: 100 m (328 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. Wall Performance Two wooden walls with thickness < 3.8 cm (1.5”) One concrete wall with thickness < 10 cm (4”) Interfaces Physical Buttons Reset Button 10/100 Mbps RJ45 Ports 4 Ethernet Notes One port supports WAN/LAN configuration, and the rest are LAN ports LED System Power Input DC Jack Power Power Methods DC DC 12V 1A Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC Reliability ESD Air Protection 4kV ESD Contact Protection 8kV Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing Package Content Main Product Power Adapter Ethernet Cable Installation Guide Mechanical Installation Desktop Wall-Mounting
