AX3000 2.5G Wi-Fi 6 Access Point ( AP3000_P)

Model Version AP3000 1.0 CPU Chipset MT7981BA+MT7976CN+RTL8221B-VB-CG CPU Details 1.3 GHz Dual-Core CPU Memory/Stroage Flash/ROM 256 MB (2 Gbit) NAND DDR/RAM 512 MB (4 Gbit) DDR4 Wireless 5 GHz Wi-Fi Speed 2402Mbps Wi-Fi Bands EU + DFS, US + DFS 2.4 GHz Wi-Fi Speed 574 Mbps 5 GHz Wi-Fi Streams 3T3R (3×3 MIMO) 2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO) Wi-Fi Antennas 5× Internal 5 GHz Anntenna Gain Max 5.6 dBi 2.4 GHz Antenna Gain Max 4.8 dBi FEM or PA/LNA 5 GHz: 3× High-Power 2.4 GHz: 2× High-Power Range Performance Max: 130 m (427 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. Wall Performance Three wooden walls with thickness < 3.8 cm (1.5”) One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”) Wi-Fi Transmission Power CE: <20 dBm (2.4 GHz) <23 dBm (5.15 GHz ~ 5.35 GHz) <30 dBm (5.47 GHz ~ 5.725 GHz) FCC: <24 dBm (5.25 GHz ~ 5.35 GHz & 5.47 GHz ~ 5.725 GHz) <30 dBm (2.4 GHz & 5.15 GHz ~ 5.25 GHz & 5.725 GHz ~ 5.825 GHz) Interfaces 2.5G RJ45 Ports 1 Ethernet Notes Accepts PoE powering LED System Physical Buttons Reset Button Power Input DC Jack, PoE via Ethernet Port Power Power Methods DC 802.3at/af PoE Passive PoE DC 12V 1.5A Passive PoE 48 ~ 57V Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1.5A DC Max Power Consumption (W) 12 W (48 V PoE) 12 W (DC) Idle Power Consumption (W) 6.1 (48 V PoE) 6.1 W (DC) Reliability System Stability Watchdog ESD Air Protection 4kV ESD Contact Protection 8kV Environment Operating Temperature: -10 ℃ ~ 60 ℃ (14 ℉ ~140 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing Mechanical Installation Wall-Mounting Ceiling-Mounting Dimension Φ231.9×57.1 mm Φ9.13×2.25 inches Package Content Main Product Power Adapter Mounting Kit Ethernet Cable Installation Guide
