AX3000 2.5G Wi-Fi 6 Mini VPN Router ( TR3000 1.0 )

Model Version TR3000 1.0 CPU CPU Details 1.3 GHz Dual-Core, ARM Cortex-A53 Memory/Stroage Flash/ROM 128 MB (1 Gbit) NAND DDR/RAM 512 MB (4 Gbit) DDR3 Wireless 5 GHz Wi-Fi Speed 2402 Mbps Wi-Fi Bands EU + DFS, US + DFS 2.4 GHz Wi-Fi Speed 574 Mbps 5 GHz Wi-Fi Streams 3T3R (3×3 MIMO) 2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO) Wi-Fi Antennas 2× Fixed, 1× Internal 5 GHz Anntenna Gain Max 4.8dBi 2.4 GHz Antenna Gain Max 3.9dBi FEM or PA/LNA 5 GHz: 3× Internal 2.4 GHz: 2× Internal Range Performance Max: 120 m (394 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. Wall Performance Two wooden walls with thickness < 3.8 cm (1.5”) One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”) Wi-Fi Transmission Power CE: <20 dBm (2.4 GHz) <23 dBm (5.15 GHz ~ 5.35 GHz) <30 dBm (5.47 GHz ~ 5.725 GHz) FCC: <24 dBm (5.25 GHz ~ 5.35 GHz & 5.47 GHz ~ 5.725 GHz) <30 dBm (2.4 GHz & 5.15 GHz ~ 5.25 GHz & 5.725 GHz ~ 5.825 GHz) Interfaces 2.5G RJ45 Ports 1 Gigabit RJ45 Ports 1 Ethernet Notes The 2.5G port is WAN port, the Gigabit port is LAN port USB-A 3.0 Ports 1 LED System Physical Buttons Reset Button Configurable DIP Switch Power Input USB-C Port Power Power Methods DC / PD DC 5V 3A, PD Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC Output: 5V 3A DC Reliability Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing Mechanical Installation Desktop Dimension 118×80×27.5 mm 4.65×3.15×1.08 inches Product Weight 160 g (5.64 oz.) Package Content Main Product Power Adapter Ethernet Cable Installation Guide
