AX3000 2.5G Mesh Wi-Fi 6 System White M3000 2.0 ( 2Pack )

Model Version M3000 2.0 CPU CPU Details 1.3 GHz Dual-Core, ARM Cortex-A53 Memory/Stroage Flash/ROM 128 MB (1 Gbit) NAND DDR/RAM 256 MB (2 Gbit) DDR3 Wireless 5 GHz Wi-Fi Speed 2402 Mbps Wi-Fi Bands EU + DFS, US + DFS 2.4 GHz Wi-Fi Speed 574 Mbps 5 GHz Wi-Fi Streams 3T3R (3×3 MIMO) 2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO) Wi-Fi Antennas 5× Internal 5 GHz Anntenna Gain Max 5.1dBi 2.4 GHz Antenna Gain Max 4.2dBi FEM or PA/LNA 5 GHz: 3× Internal 2.4 GHz: 2× Internal Range Performance Max: 130 m (427 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. Wall Performance Three wooden walls with thickness < 3.8 cm (1.5”) One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”) Wi-Fi Transmission Power CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz 5 GHz) Interfaces 2.5G RJ45 Ports 1 Gigabit RJ45 Ports 1 Ethernet Notes The 2.5G port is WAN port, the Gigabit port is LAN port LED System Speed/Link/ACT of Each Ethernet Port Physical Buttons WPS Button Reset Button Power Input DC Jack Power Power Methods DC DC 12V 1A Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC Reliability Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing Mechanical Installation Desktop Wall-Mounting Power Basic Power Saving 0 Mechanical Dimension Φ110×154.5 mm Φ4.33×6.08 inches Product Weight 1-Pack | EU / US: 360 g (12.7 oz.) 2-Pack | EU / US: 360 g (12.7 oz.) 3-Pack | EU / US: 360 g (12.7 oz.) Package Content Main Product Power Adapter Ethernet Cable Installation Guide
